Getting Started Tutorial

Product Introduction

Luckfox Pico M	Luckfox Pico Plus M
🔗 Buy Now	🔗 Buy Now
Luckfox Pico Mini A M	Luckfox Pico Mini B M
🔗 Buy Now	🔗 Buy Now

LuckFox Pico 、Luckfox Pico Mini A/B and LuckFox Pico Plus are low-cost micro Linux development boards based on the Rockchip RV1103 chip. RV1103 is a highly integrated IPC visual processing SoC designed for AI-related applications. It is built on a single-core ARM Cortex-A7 32-bit core with integrated NEON and FPU, and features a built-in NPU that supports INT4/INT8/INT16 mixed operations, with a computing power of up to 0.5 TOPs.

Furthermore, it features a new hardware-based ISP that supports various algorithm accelerators such as HDR, 3A, LSC, 3DNR, 2DNR, sharpening, haze removal, gamma correction, and more. Additionally, it has a built-in 16-bit DDR2 DRAM to maintain demanding memory bandwidth, as well as built-in POR, audio codec, and MAC PHY. In essence, the RV1103 is a powerful processor suitable for various AI application scenarios.

The development board supports multiple interfaces, including GPIO, UART, SPI, I2C, USB, etc., facilitating rapid development and debugging for developers.It's worth noting that the entire LuckFox Pico series development boards support both buildroot and Ubuntu 22.04 systems, allowing developers to choose the appropriate system based on project requirements, providing greater flexibility to meet specific application needs.

Product Parameters

	Luckfox Pico	Luckfox Pico Mini A	Luckfox Pico Mini B	Luckfox Pico Plus
Chip	Rockchip RV1103
Processor	Cortex A7 1.2GHz
Neural Network Processor (NPU)	0.5 TOPS, supports int4, int8, int16
Image Processor (ISP)	Max input 4M @30fps
Memory	64MB DDR2
Wi-Fi+Bluetooth	No
Camera Interface	MIPI CSI 2-lane
DPI Interface	No
POE Interface	No
Speaker interface	No
USB	USB 2.0 Host/Device
GPIO	24 GPIO pins	17 GPIO pins		25 GPIO pins
Ethernet	No			10/100M Ethernet controller and embedded PHY
Default Storage Medium	Micro SD Card		SPI NAND FLASH (128MB)
